SuperPro Extended Rear KDSS Sway Bar Link
Improve rear suspension travel on a lifted Lexus LX570 or Toyota Land Cruiser 200 Series equipped with KDSS using the SuperPro TRC4308 extended rear sway bar link.
Designed for vehicles with approximately 50mm or more of suspension lift, this link features a 50mm extension at the sway bar mounting pivot compared with the original component. The extended design helps support increased suspension travel when used with compatible long-travel shocks, control arms, and other supporting suspension upgrades.
The TRC4308 uses a strong one-piece forged design with OE-specification bushings and a ball stud to maintain factory-style function and appearance. It can also assist with correcting the uneven stance commonly known as KDSS lean on modified 200 Series vehicles.
Product Features
- Extended rear sway bar link for KDSS-equipped vehicles
- Designed for lifted Lexus LX570 and Land Cruiser 200 Series models
- Recommended for vehicles with approximately 50mm or more of lift
- 50mm extension at the sway bar mounting pivot compared with OE
- Helps accommodate increased rear suspension travel
- Suitable for compatible long-travel suspension setups
- Can assist with correcting KDSS lean
- One-piece forged construction
- OE-specification bushings and ball stud
- Fixed, non-adjustable design
- Rear suspension position
- 12mm mounting-bolt diameter
- Sold individually
- SuperPro part number TRC4308
Vehicle Fitment
- 2008–2021 Lexus LX570 with KDSS
- 2008–2021 Toyota Land Cruiser 200 Series with KDSS
Important Fitment Requirements
- Vehicle must be equipped with KDSS
- Intended for lifted vehicles
- Recommended for approximately 50mm or more of suspension lift
- Supporting long-travel shocks or suspension components may be required
- Confirm the required link length for the vehicle’s suspension setup before installation
Product Specifications
- Manufacturer: SuperPro
- Product Line: Roll Control
- Part Number: TRC4308
- Product Type: Extended rear sway bar link
- Position: Rear
- Link Design: Fixed
- Construction: One-piece forged
- Mounting Bolt Diameter: 12mm
- Extension: 50mm over the OE mounting-pivot position
- Vehicle System: KDSS
- Quantity: One sway bar link
- Quantity Required: One
- Wheel Alignment Required: No
- EAN: 9317745787341
Quantity Notice
This product includes one extended rear KDSS sway bar link. It is not sold as a left-and-right pair.
Installation Note
Installation involves the vehicle’s KDSS hydraulic system and should be performed by a qualified technician familiar with KDSS-equipped Toyota and Lexus suspension systems. Confirm suspension travel and link length before completing installation.
